Limestone Mill

Limestone Mill is widely used for the grinding field of limestone After being grinded by the limestone mill, the limestone powder can be from 40 mesh to 325 mesh

Inquire Now Next:Last

Technical Parameters

Limestone Mill :

Limestone Mill is widely used for the grinding field of limestone. After being grinded by the limestone grinding mill (Raymond Mill), the limestone powder can be from 40 mesh to 325 mesh. The final powder size can be adjusted by the analyzer machine continuously.

Limestone Grinding Mill Advantages :

1. Compact structure, less floor area needed.

2. High passing ratio up to 99%,.

3. Driving system of main frame adopts airtight gearing and pulley, drives smoothly and operates reliably.

4. High Maganese Steel Roller and Ring, long durable.

5. Centralized controlled electric control system, high automaticity level.

6. Easy operation and maintenance.

Limestone Grinding Mill Workflow :

1. Use hammer crusher or jaw crusher to crush the limestone into smaller size in advance.

2. Use bucket elevator to transport the crushed limestone into hopper.

3. The vibrating feeder under the hopper sends the crushed limestone into limestone mill evenly.

4. The limestone grinding mill (Raymond Mill) grind the crushed limestone into fine powder as demand.

5. Use bagging machine to pack the limestone powder into bag.

Specification of Limestone Mill :

Model	Roller Number	Roller Size (mm)	Max. Feed Size (mm)	Output Size (mm)	Capacity (t/h)	Mainframe (kw)	Blower (kw)	Overall Size (mm)
QBM6515	3	210X150	12-20	0.613-0.033	0.25-2.0	15	11	4100X3300X4500
QBM7815	3	260X150	15-20	0.613-0.033	0.28-3.0	18.5	15	4300X3500X5100
QBM3016	3	300X150	15-20	0.613-0.033	0.35-4.0	22	18.5	5300X4100X5200
QBM9517	4	310X150	15-25	0.613-0.033	1.5-8.0	37	37	7100X5900X7900
QBM4121	5	410X210	15-25	0.613-0.044	5.0-12.0	75	75	7850X8000X9700
QBM4528	6	450X280	15-25	0.613-0.044	5.0-22.0	132	132	12550X5700X8300
